Amano PIX4000 overview
The PIX4000 is a heavy-duty economical, and fully automatic electronic time stamping recorder, as well as a time and date stamping machine ideal for:
• Document control
• Time attendance or Payroll recorder
• Date and Time stamp
• Numbering machine
Prints year, month, date, hours, minutes and seconds, 4 or 6 digit numbering. The PIX-4000 can be programmed to print up to 3 lines with any alpha numerical characters and has an Illuminated LCD display and Print area.
F E A T U R E S
Made in the USA
Heavy duty time recorder / Document stamp
Over 50 Selectable preset imprint formats:
Year (2 or 4 digits) o Month (name or number)
Hour (AM/PM or military 0-23hr)o Minute (regular 60th, 10th or 100th), Seconds (2 digit)
Numbering (4 or 6 digits)
13 selectable comments - (REC'D, SENT, PAID, VOID, FILE, FAX'D AMOUNG OTHERS)
9 selectable languages
Customized consecutive imprints up to 3 lines
Consecutive numbering with auto reset
Customized nonconsecutive imprint (2 lines)
Select 2 zone programmable print function
Automatic daylight saving time adjustment
Ink ribbon life indicator
Selectable automatic or manual print
Easy-to-replace ribbon cartridge
Quality Note:
This is a repairable machine, it is not a "throw-away" like ALL non-Amano brand clocks.
PIX4000 Benefits and features:
Large illuminated easy to read display
Illuminated print window for clear alignment of media
Print position adjustment
Optional PASSWORD PROTECTION to prevent tampering
Wall or desk mount
Optional Features, require add-on upgrades, see the list above
Full power reserve (72 hours or 400 punches)
External signal device (up to 20 weekly program times)
* * Each event can be shared on up to 7 days, this is enough for two shifts
8, 10, 1008, 1010, noon, 1228, 1230, 3, 308, 310, 428, 430 M-F 12 events (rings)
then optional saturday and sunday: Use 8 and 12, still only 12 events, you have 8 left over
Custom Print Examples:
Amano PIX4000 Specifications
- Power Adaptor: AC 120 +/- 10%, 60 Hz USA/Canada a-okay
- Power Consumption: 12VVDC Idle: 3W, Printing (Max): 6W (That's .6 Amps)
- Humidity: 14°F ~113°F (-10°C ~ 45°C)
AKA: This is designed for indoor use.
- Size ("Dimensions"): 5.9” W x 6.9” H x 6”D aka 6" Wide, 7" Tall, 6" Deep
(150 W mm x 176 H mm x 153 D mm)
- Weight: 6 lbs. (2.3 kg)
- UPC: 749282004503
IN THE BOX:
One PIX4000X
Two locking case keys
One ink ribbon, pre-installed
Owners Manual with toll-free technical support number
